Guidewires

SHOW Short Wire System







All guide wires are manufactured out of bending-resistant and torsion-proof Nitinol. Their hydrophilic coated tips, allow the wires to safely find their way even into areas and stenoses which are hard to reach. This is supported by the wire's high rigidity and controllability. Hence the guide wires are not only meant for sophisticated stent placements, but are also perfectly suited for ERCP.


The high radiopacity of the flexible hydrophilic tip facilitates exact stent placement under visual radiological control. Two different series are available: the Classic-series made in Germany and the Eco-series from MICRO-TECH as a cost-efficient alternative.




SUCCESSFUL IN PRACTICAL ROUTINE WORK

Bending resistance and rigidity account for the very good feeding properties of guide wires. In daily applications they convince by their precision, which is primarily guaranteed by the efficient transmission of the rotatory and translatory motion all the way to the tip of the wire, as applied by the surgical assistant. This makes it possible to reach into even anatomically difficult passages with ease. In addition, the tip of each wire can be perfectly seen in the X-ray control image, allowing for optimal stent positioning.


Endoscopic view

Endoscopic view


X-ray

X-ray


DISPENSER FOR EASY OPERATION

The wire can be easily ejected and retracted by means of this innovative dispenser. Owing to its compact design, the dispenser is handy and easy to operate. Rinsing the wire is also easy and fast when using the dispenser.


Dispenser guide wires

Dispenser guide wires



Key Benefits

  • Non-kinking nitinol wire

  • High level of rigidity and guidability

  • Hydrophilic, atraumatic tip

  • Working length: up to 2600 mm

  • High level of radiopacity


SPECIFICATION

REF

Maximum O.D. (in)

Working Length (cm)

Tip Style

Packaging

MTN-BM-89/26-A

.035

260

Straight

2/Box

MTN-BM-89/26-A-J

.035

260

Angle

2/Box

MTN-BM-89/45-A

.035

450

Straight

2/Box

MTN-BM-89/45-A-J

.035

450

Angle

2/Box

MTN-BM-63/26-A

.035

260

Straight

2/Box

MTN-BM-63/26-A-J

.035

260

Angle

2/Box

MTN-BM-63/45-A

.035

450

Straight

2/Box

MTN-BM-63/45-A-J

.035

450

Angle

2/Box


Click to see the detailed Specifications
